| Weight |
1.374 kg |
| Dimensions |
33.4 × 23.5 × 6 cm |
| Производител |
ASROCK
|
| Наличност |
с поръчка
|
| Гаранция, месеци |
36
|
| Серия |
PRO
|
| Процесор |
Intel 1151
|
| Чипсет |
Intel Z390
|
| BIOS |
128Mb AMI UEFI Legal BIOS with multilingual GUI support, ACPI 6.0 Compliant wake up events, DRAM, PCH 1.0V, SMBIOS 2.7 Support, VCCIO, VCCSA, VCCST, VPPM Voltage Multi-adjustment
|
| Памет, слотове |
4
|
| Аудио |
7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec), ELNA Audio Caps, Premium Blu-ray Audio support, Supports Surge Protection
|
| Мрежа |
Giga PHY Intel I219V, Gigabit LAN 10/100/1000 Mb/s, Supports Energy Efficient Ethernet 802.3az, Supports Lightning/ESD Protection, Supports PXE, Supports Wake-On-LAN
|
| Безжична мрежа |
–
|
| Конектори |
1 x 24 pin ATX Power Connector, 1 x 8 pin 12V Power Connector, 1 x COM Port Header, 1 x CPU Fan Connector (4-pin), 1 x Power LED and Speaker Header, 1 x TPM Header, 2 x USB 2.0 Headers, 2 x USB 3.1 Gen1, 3 x Chassis/Water Pump Fan Connectors
|
| Слотове |
1 x M.2 Socket (Key E), 2 x PCI Express 3.0 x16 Slots; dual at x16, 3 x PCI Express 3.0 x1 Slots, Supports AMD Quad CrossFireX and CrossFireX, supports type 2230 WiFi/BT module and Intel CNVi
|
| M.2 слот |
1xUltra M.2 (M2_1), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s and M.2 PCI Express up to Gen3x4 (32 Gb/s); 1xUltra M.2 (M2_2), supports M Key type 2230/2242/2260/2280/22110 M.2 SATA3 6.0 Gb/s and M.2 PCI Express up to Gen3 x4 (32 Gb/s)
|
| Интерфейс |
1 x Antenna Ports, 1 x D-Sub Port, 1 x DVI-D Port, 1 x HDMI Port, 1 x PS/2 Mouse/Keyboard Port, 1 x RJ-45 LAN Port with LED, 1 x USB 3.1 Gen2 Type-A Port, 1 x USB 3.1 Gen2 Type-C Port, 2 x USB 2.0 Ports, 2 x USB 3.1 Gen1 Ports, HD Audio Jacks
|
| Софтуер |
ASRock A-Tuning, ASRock XFast LAN
|
| Операционна система |
Microsoft Windows 10 64-bit
|
| Форм-фактор |
ATX
|
| Специални функции |
ASRock Full Spike Protection, ASRock Intel 4-Layer Memory POOL, ASRock Live Update & APP Shop, ASRock Super Alloy, ASRock Ultra M.2, ASRock USB 3.1 Gen2
|
